Spray booth
Topic Started: Aug 22 2016, 05:49 PM (949 Views)
des byrne
Member Avatar
des Byrne
I've built a spary booth using a big clear box from ikea and bathroom extractor fan and some flexible hose from a tumble dryer. I was wondering now what can I use for a filter to go in front of the fan and where can I get some plus is there a certain grade I need to get. I was thinking something like the paper filters that go in the extractor fans over cooker hobs but not sure if its any good also can't find any to try. anyone got any ideas thanks

Des
Edited by des byrne, Aug 22 2016, 05:49 PM.
Posted Image
Offline Profile Quote Post Goto Top

FiSe
Member Avatar
Heil Mickey!
I've seen extractor fans done by using the full kitchen fan unit. The main reason for the filter is to prevent overspray - or paint dust, if you wish - entering the motor, sticking on blades and pipework behind the blades.
Kitchen filter will do just fine, unless you are trying to shoot some 1:1 replicas in your back garden.
Filip . . . .

Posted Image

Offline Profile Quote Post Goto Top

des byrne
Member Avatar
des Byrne
Cheers FiSe
Posted Image
Offline Profile Quote Post Goto Top

Parkadge
Member Avatar


Any chance of a photo Des to show people how simple this is to do?
Pat McGrath

Work to become not to acquire


Posted Image

Offline Profile Quote Post Goto Top

Barry
Member Avatar

I built one a while back and didn't find the bathroom fan up to the task to be honest...now two bathroom fans just might work
Offline Profile Quote Post Goto Top

des byrne
Member Avatar
des Byrne
Parkadge
Aug 22 2016, 08:47 PM
Any chance of a photo Des to show people how simple this is to do?
I'll take a pic tonight pat I'm in work at the moment
Posted Image
Offline Profile Quote Post Goto Top

des byrne
Member Avatar
des Byrne
Barry
Aug 22 2016, 08:55 PM
I built one a while back and didn't find the bathroom fan up to the task to be honest...now two bathroom fans just might work
I just got one fan but at the start I was thinking two side by side i suppose I could add another one
Posted Image
Offline Profile Quote Post Goto Top

des byrne
Member Avatar
des Byrne
Here's a few pics of the spray booth as requested it's pretty basic and easy to make I haven't sprayed anything yet so don't know how it performs but hopefully it will do the job
The box cost 7 euro in ikea
The fan cost 22 euro in woodies
And I picked up a filter yesterday in woodies for 6.99 for a pack of 2
The hose I had already but I think there 17 euro in woodies so in all it would cost just over 50 euro which is a good price for a decent size spray booth plus I'm sure if you shopped around you could build one much cheaper

Posted Image

Posted Image

Posted Image

Posted Image

Posted Image
Edited by des byrne, Aug 23 2016, 01:39 PM.
Posted Image
Offline Profile Quote Post Goto Top

Dermot
Member Avatar


Nice one Des and nice work set-up too. :>

Is the fan plug-and-play or do you have to wire it in somehow?

Cheers,
Dermot

Gallery of my Completed Builds

On the Bench

Posted Image
Offline Profile Quote Post Goto Top

des byrne
Member Avatar
des Byrne
Dermot
Aug 23 2016, 02:31 PM
Nice one Des and nice work set-up too. :>

Is the fan plug-and-play or do you have to wire it in somehow?

Cheers,
Dermot

Cheers Dermot it needs to be wired and doesn't come with cable I had some left over so I used theat it's just a live and neutral connection so just wired the fan and the attached a plug and it's ready to go it will run constantly though so if you have a socket with a switch it's handy as it will save you having to unplugged every time plus to make the booth only took me 30 to 40 minutes
Posted Image
Offline Profile Quote Post Goto Top

des byrne
Member Avatar
des Byrne
Gave the spray booth its first run today just spraying some small parts that's left to go on the gekko and It works well no strong smell of fumes when finished plus I didn't wear my mask and didn't get that feel/taste in my throat that I got before when I was using no mask or booth so all in all it does the job
Edited by des byrne, Sep 3 2016, 05:41 PM.
Posted Image
Offline Profile Quote Post Goto Top

Norton

Looks good.
Saw a clip on battery powered reading light recently somewhere that would go well with that.

would try if I had the space - but right now all my gear must be fold-able, stash-able.
Offline Profile Quote Post Goto Top

Maurice

Well done Des, looks great. Can I ask the shelves you have your paints on was that diy or store bought. Would save me having to root through box.
Maurice
Most important model--the one I have yet to build

Posted Image
Offline Profile Quote Post Goto Top

des byrne
Member Avatar
des Byrne
I'll keep my eye out for those Norton.
Posted Image
Offline Profile Quote Post Goto Top

des byrne
Member Avatar
des Byrne
Maurice
Oct 4 2016, 03:34 PM
Well done Des, looks great. Can I ask the shelves you have your paints on was that diy or store bought. Would save me having to root through box.
Maurice
I built the shelves myself maurice I put up the build of them on here somewhere

There in the man cave topic on page 2 of general discussion thread I've put the measurements and what you need on it to build them they don't take long to put together
Edited by des byrne, Oct 4 2016, 04:01 PM.
Posted Image
Offline Profile Quote Post Goto Top

Gertney

Nice job on the spray booth Des. Nice setup as well.
Offline Profile Quote Post Goto Top

Maurice

Thanks Des, might have a go copying it. Not too sure how good my carpentry is.
